Trio Linker Plus II

Product no.0603                                                                                        Order Form



WEIGHT : 155 g
PACKING SIZE : 14 cm X 20 cm X 3.2 cm
PRODUCT SIZE : 9 cm  X 7 cm X 1.7 cm

________________________________________________________________________________________________

Main Features
1. Supports PS2™, GC™ and DC™ controllers on PC simultaneously.

2. Compatible with official PS2™, GC™, DC™ controllers and a majority of compatible controllers.
3. Supports Joy2key, Key Mapping and force feedback function. *
4. Supports Plug and Play.

5. Also supports PS2™, GC™ and DC™ controllers on PS3™ console.

　

　

note : i. PS3™ games are supported, but PS3™ firmware must be updated.

         ii. Some PS3™ games would only recognize Sony official PS3™ controllers.

              Any other non-official controllers or adaptors would not work on those games.

        iii. GC™ / DC™ joypads have less buttons then PS2™ joypads, thus

             some buttons of PS2™/PS3™ joypads are not supported.

　

   * function 3 is only workable with driver installed.

　

 ** With (#9912) Total Control 3, it also supports SS™ controllers on PS3™.

      For details, please have a look at here.

 ** With (#0902) Classic Linker Plus, it also connects Wii™ Classic controllers to PC.

      For details, please have a look at here.

　

　

#0603 Trio Linker Plus II Supports :
 - DC TM Official Arcade Stick.                                             - PSTM steering wheel

- DC TM Official Virtual On Stick – Twin Stick TM.                   - GCTM drums

- DC TM Official Steeling Wheel.
　

Note : PSX™ / GC™ / DC™  dance mat is not supported.

________________________________________________________________________________________________

　

Installation procedure:

1. Double click the setup file (.exe) in the floppy disk to install the driver. If you don’t have a floppy drive or if you have lost the floppy disk, please download it from here.

2. Connect your PS2™ / GC™ / DC™ controllers to the adaptor, and then connect the adaptor to PC (USB port).

3. Go to "Control panel" --> "Game options", you could find one to three joypads inside, depends on how many joypads are connected to the adaptor.

4. Right click the joypads shown in the game options and select "property", the driver interface would pop up. In which, you could configure the key mapping / joy2key / force feedback function.

Note:
1. It also works without the official driver, but you would then not able to use the key mapping /joy2key /force feedback function provided by the official driver.

2. If the PC could not detect the joypads or if it could only recognize an unknown device, please reconnect the adaptor or try another USB port. If it still doesn’t work, please shut down the computer and then open it and try again. (not reboot, but turn OFF and turn ON)

3. Every time after you have connected a joypad to the adaptor, you should reconnect the adaptor to PC, such that the PC could detect the new plugged joypad.
　

________________________________________________________________________________________________

　

Q&A

　

Designated trademarks and brands are the properties of their respective owners.
#0603 Trio Linker Plus II is fully designed and developed in-house by EMS Production Ltd.

　
